High Stability P6.67 HD Module LED Display, Easy To Install And Maintain

Name: High Stability P667 HD Module LED Display Easy To Install And Maintain
Brand: Shichuangxinke
Price: 1 USD

Cheap High Stability P6.67 HD Module LED Display, Easy To Install And Maintain for sale

Brand Name : Shichuangxinke

Model Number : SCXK-P6.67

Certification : CE RoHS FCC CCC TUV UL

Place of Origin : China ,Guang Dong

MOQ : 1 square meters

Price : negotiation

Payment Terms : L/C, T/T, Western Union, D/A, D/P, MoneyGram

Supply Ability : 5000sqm per month

Delivery Time : 7 working days after deposit payment received

Packaging Details : wooden box flight case, wooden case, carton, it is up to you.

Pixel : 6.67mm

Pixel configuration : red green blue

Scanning Mode : 1/8

Module Size : 320x160mm

HS Code : 8528591090

application : airport,wall,church wedding,exhibition stand

Driver IC : MB5024/MB5124

warranty : 2-3 years

Cabinet Size : 640x640mm

Contact Now

P6.67 Front Access Module LED Display for Easy Install & Maintenance

Customer Service:

1) Warranty Period: One year after shipment from the factory
2) Warranty coverage: LED modules, power supplies, control systems and other accessories (this warranty does not cover accessories purchased from other manufacturers)
3) Repair Method:
Repair, express delivery, etc.
4) Repair response time:
Repair method: Upon receipt of the returned product, the repair will be completed and returned to the user within 24 hours;
Telephone or Internet: Contact the user within 2 hours after receiving the information, and solve the problem within 8 hours;
On-site mode: (domestic users only) after receiving the repair report, users in Guangdong Province within 48 hours to give a reply, users outside Guangdong Province within 72 hours to give a reply. Under special circumstances, the two sides will solve the problem by friendly negotiation.

Specifications :

outdoor SMD P6.67
Resolution/mm	6.67
Pixel configuration	1R1G1B
Pixel density/pixels/m²	22478/m²
Module resolution	48x24
Module size/mm	320x160mm
View distance	14-300m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>7500cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/4SCANNING
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted
	255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Self-check technology	LED spot self-check, communications check, power check,
	temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault,
	send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection, anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

Advantages:

1. High temperature resistant and aging resistant PC materials are applied in the modules to get rid of the mosaic problem even after long time use.
2. High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown, even under direct sunlight.
3. The cabinets, featuring great moisture and corrosion proofing, enable themselves to work in all weather conditions.
